Diagnostic code table
(*1)
: Pickup coil
(*2)
: Engine temperature sensor
(*3)
: Intake air temperature sensor
(*4)
: Intake air pressure sensor
(*5)
: Thermo sensor
(*6)
: “NO-WAKE MODE” switch
(*7)
: Reverse sensor
Code No. Symptom
Diagnostic code output
Multifunc-
tion meter
YDIS
Diagnosis
Diagnosis
record
01 Normal ——
13 Pulser coil
(*1)
malfunction
15 Engine temp sensor
(*2)
malfunction
17 Knock sensor malfunction
19 Battery voltage malfunction
23 Intake temp sensor
(*3)
malfunction
24 Cam position sensor malfunction
29 Intake press sensor
(*4)
malfunction
47 Slant detection switch malfunction —
55 Steering sensor malfunction
65
EX. manifold water temp. sensor
(*5)
malfunction
68
No-Wake mode switch
(*6)
malfunction
78 Reverse switch
(*7)
malfunction
112, 113, 114,
115, 116, 117,
118, 119, 121,
122, 123, 129,
136, 137, 138,
139, 141, 142,
143, 144, 145
Electronic throttle system
malfunction
124, 125, 126,
127, 128
Throttle position sensor
malfunction
131, 132, 133,
134, 135
Accelerator position sensor
malfunction
