NOTE:
______________________
__
Align the arrow mark on the clutch boss and
pressure
plate. mark.
9.
Install the clutch pressure plate and the
five clutch springs. Torque the clutch
plate bolts
to
specification.
TIGHTENING TORQUE:
8
Nm
(O.8m
'kg,
5.8ft
·lb)
10.
Place
a small piece
of
rolled rug or a
piece
of
lead
between the primary drive
gears
as
shown
in
the photograph. It will
hold the gears
so
you can tighten the
primary-drive securing nut. Torque the
nut
to
specification, and bend the lock
tab against a nut flat.
TIGHTENING TORQUE:
110
Nm
(11.0m
'kg,
80ft
·lb)
3-35
K.
Clutch
Mechanical
Adjustment
With the crankcase index mark and
the
pointed end
of
the push lever
in
line with each
other, adjust the pushrod and then secure
it
with the locknut.
1. Locknut
