12 YASKAWA ELECTRIC TOBP C730600 29G 1000-Series Option JVOP-180 Installation Manual
4 Option Components
4 Option Components
◆ Option
Figure 1
Figure 1 Option Components
A – LCD Display
<1> REV: Display option version; PRG: Language data.
D – Installation Mounting Holes
B – ALARM (ALM) LED E – Nameplate
<1>
C – Keys F – Communication Cable Connector
S / N : J007XE273710001
B
A
C
E
F
D
D
