1 Preface and Safety
YASKAWA ELECTRIC TOBP C730600 29G 1000-Series Option JVOP-180 Installation Manual 5
◆ Applicable Documentation
The following manuals are available for the JVOP-180 LCD Operator Option:
Note: Check the option to make sure it is compatible with the A1000. The nameplate on the option
must list software number PRG: 0101 or later for compatibility with A1000.
◆ Terms
LCD Operator
Yaskawa AC Drive 1000-Series
Option LCD Operator
Installation Manual
Manual No: TOBP C730600 29
(this book)
Read this manual first.
The installation manual is packaged with the option
and contains information required to install the
option and set up related unit parameters.
Yaskawa Unit
Yaskawa AC Drive
1000-Series Quick Start Guide
The unit manuals cover basic installation, wiring,
operation procedures, functions, troubleshooting,
and maintenance information.
The manuals also include important information
about parameter settings and unit tuning. Access
these sites to obtain Yaskawa instruction manuals:
U.S.: http://www.yaskawa.com
Europe: http://www.yaskawa.eu.com
Japan: http://www.e-mechatronics.com
For questions, contact your local Yaskawa sales
office or the nearest Yaskawa representative.
Yaskawa AC Drive
1000-Series Technical Manual
YASKAWA D1000 Series
Power Regenerative Converter
Instruction Manual
YASKAWA R1000 Series
Power Regenerative Unit
Instruction Manual
Note: Indicates a supplement or precaution that does not cause unit damage.
≥ PRG: 1012:
Indicates a unit feature or function that is only available in unit software version 1012 or
greater.
LED: Light emitting diode.
LCD: Liquid crystal display.
Option: YASKAWA 1000-Series Option LCD Operator
Unit: • YASKAWA AC Drive 1000-Series
• YASKAWA D1000 Series Power Regenerative Converter
• YASKAWA R1000 Series Power Regenerative Unit
