YASKAWA 1000 Series Installation Manual

YASK AWA E LEC TRI C TOBP C730600 29G 1000-Series Option JVOP-180 Installation Manual 3
Table of Contents
1 PREFACE AND SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
2 PRODUCT OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
3 RECEIVING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
4 OPTION COMPONENTS. . . . . . . . . . . . . . . . . . . . . . . . . . . .12
5 INSTALLATION PROCEDURE . . . . . . . . . . . . . . . . . . . . . . .22
6 BASIC OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
7 RELATED PARAMETERS . . . . . . . . . . . . . . . . . . . . . . . . . .51
8 OPTION FAULT DIAGNOSTICS. . . . . . . . . . . . . . . . . . . . . .54
9 SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
10 REVISION HISTORY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

YASKAWA 1000 Series Specifications

General

Series	1000 Series
Category	DC Drives
Cooling Method	Forced air cooling
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Communication Interface	Modbus RTU
Storage Temperature	-20°C to +60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Input Voltage	200-240V AC, 380-480V AC
