YASKAWA 1000 Series Installation Manual

6 Basic Operation
34 YASKAWA ELECTRIC TOBP C730600 29G 1000-Series Option JVOP-180 Installation Manual
Read/Copy Function Procedure
•Read
Reads and saves parameter settings from the drive to the option.
Note: The option can perform the Read function an estimated 100,000 times.
• Copy
Copies parameter settings from the option to another Yaskawa drive.
These parameters control the Copy function of the digital operator. The Copy function
stores parameter settings into the memory of the digital operator to facilitate the transfer
of those settings to other drives that are the same model, capacity, and same control mode
setting.
Note: Parameter settings can only be copied to other drives that are the same model, capacity, and have
the same control mode setting.
•Verify
Verifies that parameter settings in the drive match the parameter settings saved to the
option.
The following procedure is used to read parameters from the drive.
Note: Set parameter o3-02 (Read Allowable) to 1 (Enable) to read the parameter settings from the
drive.
Set parameter o3-02 to 0 (Disable) to protect the parameter settings in the option.
Procedure LCD Display
1. Frequency Reference display.
2. Press to select the Programming Mode.
3. Press to show the Initialization display.
- MODE -
U1-01= 6.00Hz
U1-02= 0.00Hz
U1-03= 0.00A
DRV
LSEQ
LREF
FREF (OPR)
Rdy
JOG FWD FWD/REV
HELP
-MODE- PRG
DATA
Programming
FWD
←→
-PRMSET-
Initialization
Select Language
PRG
FWD
A1-00=0
