YASKAWA 1000 Series Installation Manual

6 Basic Operation
38 YASKAWA ELECTRIC TOBP C730600 29G 1000-Series Option JVOP-180 Installation Manual
Procedure Example: Viewing Monitors
5. Press to start the operation at the set voltage while the RUN LED is
on.
6. Press to stop the operation. The RUN LED will be off when the
converter comes to a complete stop.
Procedure LCD Display
1. DC Bus Voltage Reference display.
2. Press until the Monitor Menu display appears.
3. Press to show the Monitor display.
4. Press to view the converter monitors.
Procedure LCD Display
RUN
- MODE -
U1-51= 320V
U1-52= 320V
LSEQ
LREF
U1-53= 5.0A
DRV
Volt Ref
Rdy
- MODE -
U1-51= 320V
U1-52= 295V
U1-53= 0.0A
DRV
Volt Ref
Rdy
LSEQ
LREF
- MODE -
U1-51= 320V
U1-52= 295V
U1-53= 0.0A
DRV
Monitor Menu
Rdy
LSEQ
LREF
-MONITR-
U1-51= 320V
U1-52= 295V
U1-53= 0.0A
DRV
Monitor
Rdy
LSEQ
LREF
-MONITR-
U2-02= oPr
U2-11=
00000000
U2-12= 00000000
DRV
LSEQ
LREF
Last Fault
Rdy
