Page #218 background image
Drive
Model
Heavy Duty (Carrier Frequency 8 kHz) Normal Duty (Swing PWM equal 2 kHz)
Rated
Amps (A)
Heatsink
Loss (W)
Interior
Unit Loss
(W)
Total
Loss (W)
Rated
Amps (A)
Heatsink
Loss (W)
Interior
Unit Loss
(W)
Total
Loss (W)
4A0004 3.4 42.3 17.9 60.2 4.1 30.5 16.8 47.3
4A0005 4.8 70.7 26.2 96.9 5.4 44.5 21.8 66.3
4A0007 5.5 81.0 30.7 111.7 6.9 58.5 28.4 86.9
4A0009 7.2 84.6 32.9 117.5 8.8 63.7 31.4 95.1
4A0011 9.2 107.2 41.5 148.7 11.1 81.7 46.0 127.7
A.5 Drive Watt Loss Data
218
YASKAWA ELECTRIC TOEP C710606 25D YASKAWA AC Drive J1000 Installation & Start-Up Manual
