YASKAWA CIMR-JB Series - LO;RE LED and RUN LED Indications

Display Lit Flashing Off
As illustrated
in this
manual
STOP
u
LO/RE LED and RUN LED Indications
LED Lit Flashing
Flashing Quickly
<1>
Off
When a Run command
is selected from the
LED operator
(LOCAL)
– –
Run command is selected
from device other than LED
operator (REMOTE)
During Run
• During deceleration to
stop
• When a Run
command is input and
frequency reference
is
0
• During deceleration
at a fast-stop.
• During stop by
interlock operation.
During stop
As shown
<1> Refer to Figure 4.1 for the difference between “flashing” and “flashing quickly”.
Flashing
ON ON
ON
ON ON
ON
1 s
Flashing
quickly
Figure 4.1 RUN LED Status and Meaning
