Table C.3 Three-Phase 200 V Class Fuses and Fuse Holders
Drive Model
DC Power Supply Input
Fuse Fuse Holder
Manufacturer: Fuji Electric
Type
Rated Short
Circuit Braking
Current (kA)
Qty. Type Qty.
2A0001 CR6L-20/UL
100 2
CMS-4
2
2A0002 CR6L-20/UL CMS-4
2A0004 CR6L-20/UL CMS-4
2A0006 CR6L-30/UL CMS-4
2A0008 CR6L-50/UL CMS-4
2A0010 CR6L-50/UL CMS-4
2A0012 CR6L-50/UL CMS-4
2A0018 CR6L-75/UL CMS–5
2A0020 CR6L-75/UL CMS–5
Table C.4 Three-Phase 400 V Class Fuses and Fuse Holders
Drive Model
DC Power Supply Input
Fuse Fuse Holder
Manufacturer: Fuji Electric
Type
Rated Short
Circuit Braking
Current (kA)
Qty. Type Qty.
4A0001 CR6L-20/UL
100 2
CMS-4
2
4A0002 CR6L-20/UL CMS-4
4A0004 CR6L-50/UL CMS-4
4A0005 CR6L-50/UL CMS-4
4A0007 CR6L-50/UL CMS-4
4A0009 CR6L-50/UL CMS-4
4A0011 CR6L-50/UL CMS-4
n
Guarding Against Harmful Materials
When installing IP20/Open-Chassis enclosure drives, use an enclosure that prevents foreign
material from entering the drive from above or below.
u
EMC Guidelines Compliance
This drive is tested according to IEC/EN 61800-3 and it complies with the EMC guidelines.
C.2 European Standards
258
YASKAWA ELECTRIC TOEP C710606 25D YASKAWA AC Drive J1000 Installation & Start-Up Manual
