YASKAWA CIMR-JB Series - H Parameters: Multi-Function Terminals

No. Name Description Range Def. Mode
Addr.
Hex
Pg.
E2-02 Motor Rated
Slip
Sets the motor rated slip in Hertz.
0.00 to
20.00
<2> O 30F 110
E2-03
Motor
No-Load
Current
Sets the magnetizing current of the motor in amperes.
Note: Set E2-03 (Motor No-Load Current) before
making
changes
to
E2-01.
Setting
E2-01
<
E2-03 will
trigger an oPE02 error.
0 to less
than
E2-01
<2> O 310 110
E2-05
Motor
Line-to-Line
Resistance
Sets the phase-to-phase motor resistance in ohms.
0.000 to
65.000
<3>
<2> O 312 –
<1> Values shown here are for 200 V class drives. Double the value when using a 400 V class drive.
<2> Default
setting
value
is
dependent
on
parameter
o2-04, Drive Model Selection and C6-01, Drive Duty Selection.
<3> Setting range becomes 0.00 to 130.00 for drives 0.2 kW and smaller.
<4>
The default value is for the following localized drives: Japan (Model code: CIMR-JAoA) and Asia (Model
code: CIMR-JToA) .Refer to China Localized Drive Default Values on page 246 for the default values of
China localized (Model code: CIMR-JBoA) drives.
u
H Parameters: Multi-Function Terminals
H parameters assign functions to the multi-function input and output terminals.
No. Name Description Range Def. Mode
Addr.
Hex
Pg.
H1: Multi-Function Digital Input
H1 parameters to assign functions to the
multi-function digital input terminals. Unused terminals should be set to "F".
H1-01
Multi-Function Digital
Input Terminal S1
Function Selection
Assigns a function to the multi-function
digital inputs.
Refer to H1 Multi-Function Digital Input
Selections on page 232 for a description
of setting values.
1 to 67
40 O 438 –
H1-02
Multi-Function Digital
Input Terminal S2
Function Selection
41 O 439 –
H1-03
Multi-Function Digital
Input Terminal S3
Function Selection
0 to 67
24 O 400 –
H1-04
Multi-Function Digital
Input Terminal S4
Function Selection
14 O 401 –
H1-05
Multi-Function Digital
Input Terminal S5
Function Selection
3 (0)
<1>
O 402 –
<1> Parenthetical value is the default when parameter A1-03 = 3330 3-Wire Initialization.
B.2 Parameter Table
