d: References
Reference parameters are used to set the
various frequency reference values during operation.
No. Name Description Range Def. Mode
Addr.
Hex
Pg.
d1: Frequency Reference
Use d1 parameters to configure the drive frequency reference.
d1-01
<1>
Frequency
Reference 1
Frequency reference. Refer
to
Frequency
Reference
Source:
b1-01 on page 94
for instructions to use
d1-01 as the main frequency reference.
0.00 to
400.00
Hz
<2>
0.00
Hz
S
280 103
d1-02
<1>
Frequency
Reference 2
Frequency reference when digital input "Multi-Step
Speed Reference 1" (H1-oo = 3) is on.
0.00
Hz
S
281 103
d1-03
<1>
Frequency
Reference 3
Frequency reference when digital input "Multi-Step
Speed Reference 2” (H1-oo = 4) is on.
0.00
Hz
S 282 103
d1-04
<1>
Frequency
Reference 4
Frequency reference when digital inputs "Multi-Step
Speed Reference 1, 2" (H1-oo = 3 and 4) are on.
0.00
Hz
S 283 103
d1-05
<1>
Frequency
Reference 5
Frequency reference when digital input "Multi-Step
Speed Reference 3" (H1-oo = 5) is on.
0.00
Hz
O 284 –
d1-06
<1>
Frequency
Reference 6
Frequency reference when digital inputs "Multi-Step
Speed Reference 1, 3 " (H1-oo = 3 and 5) are on.
0.00
Hz
O 285 –
d1-07
<1>
Frequency
Reference 7
Frequency reference when digital inputs "Multi-Step
Speed Reference 2, 3" (H1-oo = 4 and 5) are on.
0.00
Hz
O 286 –
d1-08
<1>
Frequency
Reference 8
Frequency reference when multi-function input
"Multi-Step
speed reference 1, 2, 3" (H1-oo
= 3, 4,
5) are on.
0.00
Hz
O 287 –
d1-17
<1>
Jog Frequency
Reference
Frequency reference when digital inputs "Jog
Frequency Reference", "Forward Jog" or "Reverse
Jog." are on.
6.00
Hz
S 292 –
d2: Frequency Upper and Lower Limits
Use d2 parameters to configure the frequency reference limits.
d2-01
Frequency
Reference
Upper Limit
Sets the frequency reference upper limit as a
percentage of maximum output frequency (E1-04).
Output speed is limited to this value even if the
frequency reference is higher. This limit applies
to all
frequency reference sources.
0.0 to
110.0
100.
0%
O 289 –
d2-02
Frequency
Reference
Lower Limit
Sets the frequency reference lower limit as a
percentage of maximum output frequency (E1-04).
Output speed is limited to this value even if the
frequency reference is lower. This limit applies to all
frequency reference sources.
0.0 to
110.0
0.0% O 28A –
d3: Jump Frequency
Use d3 parameters to configure the drive Jump Frequency settings.
B.2 Parameter Table
228
YASKAWA ELECTRIC TOEP C710606 25D YASKAWA AC Drive J1000 Installation & Start-Up Manual
