No. Name Description Range Def. Mode
Addr.
Hex
Pg.
o2-04 Drive Model
Selection
Sets the drive model.
This
parameter
only
needs
to
be
set
when installing a
new control board. Do not change for other reason.
0 to FF
dep.
on
drive
spec.
O 508 –
o2-05
Frequency
Reference
Setting
Method
Selection
Selects if the ENTER key must be pressed when
inputting the frequency reference by the operator
keypad.
0: Data/Enter key must be pressed to enter a frequency
reference.
1: Data/Enter key is not required.
The output frequency changes immediately when the
reference is changed by the UP or DOWN keys on the
digital operator. The ENTER key does not need to be
pressed.
Note: When o2-05 is set to 1, the power supply to the
drive must remain on for at least 5 seconds after
making changes to the frequency reference.
0, 1 0 O 509 –
o2-06
Operation
Selection
when Digital
Operator is
Disconnected
Sets drive action when the digital operator is removed
in LOCAL mode or with b1-02 = 0 (valid for optional
remote operator only).
0: The drive will continue operation
1: The drive will trigger a fault (oPr) and the motor
will coast to stop
0, 1 0 O 50A –
o2-09 – Factory use. – – – – –
o3: Copy Function
Use o3 parameters to Read, Copy and Verify the parameter settings to and from the drive.
o3-01
Copy
Function
Selection
0: Copy select
1: INV → OP READ (Read parameters from the
drive, saving them onto the digital operator.)
2: OP → INV WRITE (Copy parameters from the
digital operator, writing them to the drive.)
3: OP → INV VERIFY (Verify parameter settings on
the drive to check if they match the data saved on the
operator.)
To read the drive parameter settings into the digital
operator, set o3-02 to 1 (to allow reading).
0 to 3 0 O 515 –
o3-02
Copy
Allowed
Selection
Locks the READ operation to prevent accidental
overwriting of the data stored in the LED operator.
0: READ operation prohibited
1: READ operation allowed
0, 1 0 O 516 –
o4: Maintenance Period
Use o4 parameters to perform maintenance.
o4-01
Accumulated
Operation
Time Setting
Sets the value for the cumulative operation time of the
drive in units of 10 h.
0 to
9999
0 O 50B –
o4-02
Accumulated
Operation
Time
Selection
Determines, how the cumulative operation time
(U4-01) is counted.
0: Logs power-on time
1: Logs operation time when the drive output is active
(output operation time).
0, 1 0 O 50C –
B.2 Parameter Table
242
