Reattaching the Protective Covers
Properly connect all wiring and route power
wiring away from control signal wiring. Reattach
all protective covers when wiring is complete. Apply only a small amount of pressure to lock
the cover back into place.
Figure 3.8 Reattach the Protective Covers on an IP20/Open-Chassis Drive
3.5 Protective Covers
YASKAWA ELECTRIC TOEP C710606 25D YASKAWA AC Drive J1000 Installation & Start-Up Manual
49
3
Electrical Installation
