Transportation
3 - 16
3.1.2 Using a forklift
If the robot is transported using a forklift, it should be fixed on a pallet with transport securing
devices and shipping bolts. Make sure that the forklift and the transportation route have
sufficient bearing capacity.
Always take due care when transporting the robot.
Using a forklift
4 screws M16
Pallet
Openings for the fork prongs
1
2
3
