YASKAWA JEPMC-CP3202-E - Page 172

4.3 CPU Unit Specifications
System Register Specifications
4-14
SW00800 to
SW01095
Module Information
 Module Information (page 4-29)
SW01096 to
SW01410
Reserved for system. −
SW01411 to
SW01442
MPU-01 Module Status
 MPU-01 Module Status (page 4-31)
SW01443 to
SW03199
Reserved for system. −
SW03200 to
SW05119
Motion Program Information
 Motion Program Execution Information (page 4-32)
SW05120 to
SW05247
Used by the system (system memory read). −
SW05248 to
SW08191
Reserved for system. −
SW08192 to
SW09215
Expansion Motion Program Information
 Motion Program Execution Information (page 4-32)
SW09216 to
SW09559
Reserved for system. −
SW09560 to
SW13699
Expansion System I/O Error Status
 Expansion System I/O Error Status (page 4-55)
SW13700 to
SW15795
Expanded Unit and Module Information
 Expanded Unit and Module Information (page 4-59)
SW15796 to
SW15799
Reserved for system. −
SW15800 Expansion System Status
 Expansion System Status (page 4-64)
SW15801 to
SW15997
Reserved for system.
−
SW15998 to
SW16011
Expansion System Service Execution Status
 Expansion System Service Execution Status (page 4-
64)
SW16012 to
SW16199
Reserved for system. −
SW16200 to
SW17999
Alarm History Information
 Alarm History Information (page 4-65)
SW18000 to
SW19999
Reserved for system.
−
SW20000 to
SW22063
Product Information
 Product information (page 4-67)
SW22064 to
SW22999
Reserved for system. −
SW23000 to
SW23159
Unit and Rack Information
 Unit and Rack Information (page 4-67)
SW23160 to
SW23999
Reserved for system. −
SW24000 to
SW24321
Data Logging Execution Status
 Data Logging Execution Status (page 4-69)
SW24322 to
SW24999
Reserved for system.
−
SW25000 to
SW25671
Automatic Reception Status for Ethernet
Communications
 Automatic Reception Status for Ethernet Communi-
cations (page 4-71)
SW25672 to
SW65534
Reserved for system. −
Continued from previous page.
Register
Address
Contents Details
