1.6 Digital Torque Amplifier
5
1.6 Digital Torque Amplifier
Maximum Capacity of Applied Motor
Note: Keep the following in mind in SGDG digital torque amplifier and SGDG/SGL□W
servomotor combinations:
The SGDG-01GT can drive motors of 30~200W rated output.
The SGDG-04GT can drive motors of 100~750W rated output.
The SGDG-10GT can drive motors of 300W~2kW rated output.
The SGDG-15GT can drive motors of 750W~3kW rated output.
Since LEGEND servo drives are applicable to a wider range motor and driver combinations,
the output power of the drive will dictate the available maximum motor power even if the
maximum output power of the motor is larger than that of the connected drive.
Specific speed/torque performance will vary depending on such power supply conditions as
voltage, number of available phases, etc.
Applied Motor
Maximum Capacity
Symbol
Capacity
(kW)
01 0.1
04 0.4
10 1.0
15 1.5
SGDG
-
10 G
LEGEND
SGDG Servo Amplifier
Maximum applied motor capacity
(see table below)
Voltage
G: 90V~253V
Model
@T: Torque/Force Control
