YASKAWA Legend 01 User Manual

2.1 Main Circuit Wiring
15
■ Peripheral Device Types and Capacities
Table 2.3 Shows Servopack device Types and capacities.
＊ The FN □□□□ noise filter is manufactured by Schaffner Corp.
Table 2.3: Peripheral Device Types and Capacities
Main
Circuit
Power
Supply
Model
Power Supply
Capacity Per
Amplifier
(KVA)
MCCB or
Fuse
Capacity
(Arms)
Recommended
Noise Filter*
Magnetic
Contactor
Capacity
(kW)
SGDG- Model
Specifi-
cations
Single-Phase
200V
0.1 01GT 0.40 4
FN2070-
6/07
Single-
Phase
250VAC
6A
10A or
Equivalent
0.4 04GT 1.2 8
FN2070-
10/07
Single-
Phase
250VAC
10A
20A or
Equivalent
Three-Phase
200V
1.0 10GT 2.3 7
FN258L-
16/07
Three-
Phase
480V
16A
20A or
Equivalent
1.5 15GT 3.2 10
