32 Working with MotoAdmin
4.16 Watch I/O Signals
To display I/O signals select [Disp I/O] from the main window. This opens a new window
where you can select the type of I/O signals you want to check. The following signal types are
available:
► External Inputs
► External Outputs
► Universal Inputs
► Universal Outputs
► Special Inputs
► Special Outputs
ald
·Network Outputs
IN" signals by changing the lad-
► ·AUX Relais
► ·System Status
► ·Pseudo Input Sign
► ·Network Inputs
►
Use the arrow buttons to navigate through the outputs or inputs. All outputs are read-only.
You can only write "Network IN" signals. So if there are some other signals you want to set
y MotoAdmin, you have to map these signals to "Networkb
der program of the controller (see LadderEditor software).
igure 24 I/O Signals
click on
the Refresh button. Select Close to return to the main window of the application.
F
The display of the I/O signals is static. To update the displayed values you have to
22.08.2011 Yaskawa Europe GmbH
