2.5 Communications with a Touch Panel
Using Automatic Reception with the MP3000 as a Slave
2-91
Setting Example
The following figure illustrates how the contents of the MW00100 hold register in the MP3000 slave is
displayed on the Touch Panel, and written from the Touch Panel to the same register.
TCP
MW00100
Ethernet
GMW00100
Touch Panel
(remote station)
IP address: 192.168.001.002
MP3000
(local station)
Slave
Master
Extended MEMOBUS protocol
Connection Type
Data Code
Port number: 10001
Local Station Remote Station
Read.
Written.
Hold registers (M registers)
Port number: 10001
Communications Protocol
IP address: 192.168.001.001
Binary
To Next Page
