2.1 Overview
Ethernet Communications
2-4
2.1
Overview
Ethernet Communications
Ethernet communications connects the MP3000-series Controller to Ethernet devices. The MP3000-series
Controller is equipped with one 100Base-TX Ethernet port that conforms to IEEE802.3u. It can be easily
connected to controllers manufactured by other companies, personal computers, or other types of comput-
ers. By connecting a computer running the MPE720 Integrated Engineering Tool, you can perform engi-
neering tasks on the MP3000-series Controller from the computer.
Ethernet communications can be used for message communications and engineering communications.
The MP3000-series Controller supports the following communications protocols.
The Extended MEMOBUS protocol is used for all message communications between the CPU Function
Module and the 218IFD Function Module in the CPU Unit or the CPU Module of the MP3000-series
Machine Controllers.
Protocol Description Master/Slave
MEMOBUS Yaskawa’s standard MEMOBUS protocol. Master/Slave
Extended MEMOBUS Yaskawa’s extended MEMOBUS protocol. Master/Slave
A-compatible 1E frame A protocol for Mitsubishi PLCs. Master/Slave
QnA-compatible 3E
frame
A protocol for Mitsubishi PLCs. Master/Slave
FINS A protocol for OMRON PLCs. Master/Slave
MODBUS/TCP
An Ethernet protocol proposed by Modicon and used in
industrial applications.
Master/Slave
TOYOPUC A protocol for JTEKT PLCs. Master/Slave
No-protocol
A protocol provided to implement general-purpose message
communications.
Master/Slave
This manual describes message communications using the MSG-SNDE and MSG-RCVE functions. If
you use the MSG-SND and MSG-RCV functions, substitute the corresponding information for the
MSG-SND and MSG-RCV functions. These functions are slightly different when used in ladder pro-
grams. Refer to the following manual for information on using the MSG-SND and MSG-RCV func-
tions in ladder programs.
MP2000-series Communication Module User’s Manual (Manual No.: SIEP C880700 04)
SOCKET
TCP UDP
IP, ARP, ICMP
CSMA/CD
MP3000-series Controller
Application protocol
Extended MEMOBUS
(MEMOBUS/No-protocol)
218IFD
stack
Extended MEMOBUS Protocol
(MEMOBUS/No-protocol)
Other supported protocols
MSG-SNDE and MSG-RCVE functions
CPU Function Module
To Next Page
