2.6 Communications with a Mitsubishi PLC (A-compatible 1E Frame protocol)
Message Functions
2-122
Note: 1. Even if addresses are within the given device range, they may exceed the range of the device area depending on
the model of the Mitsubishi Q/A-series PLC.
Refer to the following manual for details.
Programmable Controller Manual from Mitsubishi Electric Corporation
2. The corresponding register address in the MP3000 can be adjusted by using the offset setting of the MSG-SNDE
function.
Remote Station Register Type (PARAM16)
This parameter is not used for the A-compatible 1E Frame protocol.
Data Size (PARAM17)
Set the data size for the read/write request as the number of bits or words.
Be sure that the last data address that is determined by the offset, data address, and data size does not
exceed the valid data address range.
The range that is allowed for the data size depends on the function code and data area.
CC CC000 to CC255 Decimal 02 hex: Input relays 2816 to 3071
MB001760 to
MB00191F
M M2048 to M8191 Decimal 01, 05, and 0F hex: Coils 8192 to 14335
MB005120 to
MB00895F
Word Device Conversion Table
Device
Device Range for
ACPU Common
Instructions
Notation Function Code
Data Address
Setting Range
Correspond-
ing Register
Addresses
TN TN000 to TN255 Decimal
04 and 0A hex: Input reg-
isters
0 to 255
MW00000 to
MW00255
CN CN000 to CN255 Decimal
04 and 0A hex: Input reg-
isters
256 to 511
MW00256 to
MW00511
D D0000 to D1023 Decimal
03, 06, 09, 0B, 0E, and 10
hex: Hold registers
0 to 1023
MW00000 to
MW01023
D
(Special)
D9000 to D9255 Decimal
03, 06, 09, 0B, 0E, and 10
hex: Hold registers
1024 to 1279
MW01024 to
MW01279
W W0000 to W03FF
Hexadeci-
mal
03, 06, 09, 0B, 0E, and 10
hex: Hold registers
1280 to 2303
MW01280 to
MW02303
R R0000 to R8191 Decimal
03, 06, 09, 0B, 0E, and 10
hex: Hold registers
2304 to 10495
MW02304 to
MW10495
D D1024 to D6143 Decimal
03, 06, 09, 0B, 0E, and 10
hex: Hold registers
10496 to 15615
MW10496 to
MW15615
Function
Code
Common
Instructions for
MELSEC
ACPUs
Function Data Size Setting Range
01 or 02 hex 00 hex Reads bit devices in units of one point. 1 to 256 points
03, 04, 09, or
0A hex
01 hex Reads word devices in units of one point. 1 to 256 points
05 or 0F hex 02 hex Writes bit devices in units of one point. 1 to 256 points
06, 0B, or 10
hex
03 hex Writes word devices in units of one point. 1 to 256 points
Continued on next page.
Bit Device Conversion Table
Device
Device Range for
ACPU Common
Instructions
Notation Function Code
Data Address
Setting Range
Correspond-
ing Register
Addresses
