2.8 Communications with an OMRON PLC (FINS Communications Service)
Message Functions
2-244
Status 3 (PARAM06)
This parameter gives the value of the send pass counter.
Status 4 (PARAM07)
This parameter gives the value of the receive pass counter.
Status 5 (PARAM08)
This parameter gives the value of the error counter.
Status 6 (PARAM09)
This parameter is not used for the FINS protocol.
Connection Number (PARAM10)
Specify the remote station.
If the communications device is the 218IFD, enter the connection number. The valid setting range is given
in the following table.
Note: Enter the same connection number as displayed in the 218IFD Detail Definition Dialog Box in the MPE720.
8 UDP Data Send Error
The data send request command was sent to a socket
that does not exist.
9 TCP Data Receive Error
A disconnection request was received from the remote
station.
10 UDP Data Receive Error
A data receive request was executed for a socket that
does not exist.
11 Changing Socket Option Error
A system error occurred while changing the socket
options.
12 Data Conversion Error Error in protocol conversion
Status 3 Value Meaning Description
0 to 65535 Send Count Counts the number of times a message was sent.
Status 4 Value Meaning Description
0 to 65535 Receive Count Counts the number of times a message was received.
Status 5 Value Meaning Description
0 to 65535 Error Count
Counts the number of errors that occurred during message pro-
cessing.
Communications
Device
Connection
Number
Remarks
218IFD 1 to 20
Specifies the connection number of the remote station to receive the
message from.
Continued from previous page.
Status 2 Value Meaning Description
