2.8 Communications with an OMRON PLC (FINS Communications Service)
Message Functions
2-247
Ethernet Communications
 Offsets (PARAM20 to PARAM27)
These parameters set the offset for the data address in the MP3000.
The MP3000 will offset the address by the number of words specified by the offset.
Note: An offset cannot be a negative value.
Offset parameters are provided for each of the target register types.
The following table lists the offset parameters.
The offset parameters that can be used depend on the function code.
The following table lists the valid parameters for each function code.
 Data Relay Offset (PARAM28 and PARAM29)
These parameters are not used for the FINS protocol.
 Data Register Offset (PARAM30 and PARAM31)
These parameters are not used for the FINS protocol.
 Output Coil Offset (PARAM32 and PARAM33)
These parameters are not used for the FINS protocol.
 Output Register Offset (PARAM34 and PARAM35)
These parameters are not used for the FINS protocol.
Parameters Meaning Description
PARAM20 and
PARAM21
Coil Offset Sets the offset to the word address for a coil.
PARAM22 and
PARAM23
Input Relay Offset These parameters are not used for the FINS protocol.
PARAM24 and
PARAM25
Input Register Offset These parameters are not used for the FINS protocol.
PARAM26 and
PARAM27
Hold Register Offset Sets the offset to the word address for a hold register.
Function Code Function Applicable Offset Parameters
01 hex Reads the states of coils. PARAM20 and PARAM21
03 hex Reads the contents of hold registers. PARAM26 and PARAM27
09 hex Reads the contents of hold registers (extended). PARAM26 and PARAM27
0B hex Writes to hold registers (extended). PARAM26 and PARAM27
0D hex
Reads the contents of non-consecutive hold registers
(extended).
PARAM26 and PARAM27
0F hex Changes the states of multiple coils. PARAM20 and PARAM21
10 hex Writes to multiple hold registers. PARAM26 and PARAM27
