2.10 Communications with a JTEKT PLC (TOYOPUC Protocol)
Using Automatic Reception with the MP3000 as a Slave
2-264
Setting Example
The following figure illustrates how the contents of the 1002 to 10C9 file memory addresses in the JTEKT
PLC master are written to the MW00000 to MW00099 hold registers in the MP3000 slave.
MW00000
Ethernet
MW00001
MW00099
01002
01004
010C8
MW00098
010C6
Ethernet
TOYOPUC
Ethernet
TCP
Binary
MP3000
(local station)
JTEKT PLC TOYOPUC
(remote station)
Slave
Communications Protocol
Connection Type
Data Code
Master
Port number: 1025
Port number: 1025
Local Station
Hold registers (M registers)
Written.
Remote Station
File memory
Data size:
100 words
Connection 1
Data size:
100 words
