2.10 Communications with a JTEKT PLC (TOYOPUC Protocol)
Using the MSG-RCVE Function with the MP3000 as a Slave
2-278
Setting the Remote Device (JTEKT PLC)
Use the following procedure to set up the JTEKT TOYOPUC PLC.
1. Set the Ethernet settings and baud rate using the DIP switch on the 2PORT-EFR Module.
2. Start the PCWIN.
3. Set up the I/O Module. The identification code for a 2PORT-EFR module that has been set up to
use Ethernet communications is “B3”.
4. Set the link module name. In the Link Parameter Dialog Box, select the rack number and slot
number to assign to the 2PORT-EFR module, and set the link module name to Ethernet.
5. Set the communication parameters.
Note: When communicating with TCP and the open protocol setting on the 2PORT-EFR is set to TCP Active Open,
execute the MSG-RCVE function on the MP3000 to receive messages. If the open protocol setting on the
2PORT-EFR is set to TCP Destination - Specified Passive, or TCP Non-Specified Passive, execute
the MSG-SNDE function in the MP3000. The MP3000 is capable of operating as a TCP active node when
using the MSG-SNDE function, and as a TCP specified passive node or TCP non-specified passive node when
using the MSG-RCVE function.
TOYOPUC PLCs are manufactured by JTEKT Corporation.
Refer to the following manual for details.
Manual for the 2PORT-EFR Module from JTEKT Corporation
Ethernet Settings Example
Parameter Description
Own Node IP Address 192.168.1.2
Connection 3 Use
Open Protocol TCP Active Open
Own Node Port No. 1025
Other Node Table No. 1
Other Node Table Settings Example
Parameter Description
Table 1 Use
Other Node IP Address 192.168.1.1
Other Node Port No. 1025
Timers Settings Example
Parameter Description
Reset Wait Resending Times As required.
Non-Reception Timer As required.
Response Timer As required.
Resending Timer (Data) As required.
Resending Timer (SYN/FIN) As required.
Close Timer As required.
Packet Alive Time As required.
IP Assembly Timer As required.
Subnet Mask and Gateway IP Address Settings Example
Parameter Description
Subnet Mask 255.255.255.0
Gateway IP Address As required.
