2.12 Communications with a Windows PC (Visual Basic Application)
Using Automatic Reception with the MP3000 as a Slave
2-327
4.
Set the connection parameters.
Select
1
in the
Connect No.
Box.
Enter “10001” in the
Port No.
Box for the MP-series Controller.
Select
Extended MEMOBUS
in the
Communications Protocol Type
Box, and then click the
Default
Button.
Select
TCP
in the
Connect Type
Box.
Select
ASCII
in the
Code
Box.
Enter the following address in the
Node Port IP Address
Boxes for the other device: 192.168.001.002.
Enter “10001” in the
Port No.
Box for the other device.
5.
Click the
OK
Button.
6.
Click the
Yes
Button in the Transmission Parameters Confirmation Dialog Box.
Note: If parameters have already been set for the same connection number and you click the Yes Button in the
Transmission Parameters Confirmation Dialog Box, the settings will be overwritten by the parameters that are
set in the Message Communications Easy Setting Dialog Box.
