YASKAWA MP3000 Series - Page 35

2.2 Detail Definition Setting Procedures
218IFD Detail Definition Dialog Box Details
2-17
Ethernet Communications
 Response Time
The time (ms) that was required to receive a response for a command that was sent using the MSG-SNDE
function is displayed.
 Connection Type
The connect type (TCP or UDP) that is set in the connection parameters on the Transmission Parameters Tab
Page is displayed here.
Protocol Type
The protocol type that is set in the connection parameters on the Transmission Parameters Tab Page is dis-
played here.
Code
The code (ASCII, binary, or RTU) that is set in the connection parameters on the Transmission Parameters
Tab Page is displayed here.
Node Name (Remote Station Name)
The remote node name that is set in the connection parameters on the Transmission Parameters Tab Page is
displayed here.
11
12
13
