2.12 Communications with a Windows PC (Visual Basic Application)
Using Automatic Reception with the MP3000 as a Slave
2-339
Starting Communications
Use the following procedure to communicate between the Visual Basic application on the PC and the
MP3000.
1.
Turn ON the power to the MP3000 to start receiving messages.
The system will automatically start the message reception operation. No further operation is required.
2.
Start the application created in Visual Basic and follow these steps to start communicating with
the MP3000.
Enter the PC’s IP address. (Example: 192.168.1.2)
Set the PC’s port number. (Example: 10001)
Set the MP3000’s IP address. (Example: 192.168.1.1)
Set the MP3000’s port number. (Example: 10001)
Select the connection type. (Example: TCP)
Click the
TCP/UDP Open
Button.
Click the
Communications START
Button.
Note: Click the
Communications STOP
Button. This pauses message communications.
