2.4 Communications with MP-series Controllers
Using the MSG-RCVE Function with the MP3000 as a Slave
2-38
3. Set the connection parameters.
Enter “10002” in the Local Port Box.
Enter the following address in the Node IP Address Boxes: 192.168.001.001.
Enter “10002” in the Node Port Box.
Select TCP in the Connect Type Box.
Select Extended MEMOBUS in the Protocol Type Box.
Select BIN in the Code Box.
Note: Changes made to the communications or connection parameters will become effective only after the changes
have been saved to flash memory and the power supply has been cycled.
