2.4 Communications with MP-series Controllers
Using the MSG-RCVE Function with the MP3000 as a Slave
2-41
Starting Communications
1. Turn ON the power to the MP3000 to start receiving messages.
In the ladder program example, message reception starts immediately after the system starts. No further
operation is required.
2. Turn ON the Execute Bit (e.g., DB000200) for the MSG-SND function in the MP2300 to start
sending messages.
The ladder program example is designed to send a message every second after five seconds have elapsed
from when the low-speed scan (or high-speed scan) starts.
To change the message transmission interval, change the timer value .
To Next Page
