2.4 Communications with MP-series Controllers
Using the MSG-SNDE Function with the MP3000 as the Master
2-52
Setting Example
The following figure illustrates how the contents of the MW00400 to MW00499 hold registers in the
MP2300 slave are written to the MW00400 to MW00499 hold registers in the MP3000 master.
TCP
DC24V
DC 0V
MP2300
YASKAWA
TEST
RDY
ALM
TX
RUN
ERR
BAT
MON
CNFG
INT
SUP
STOP
SW1
OFF ON
BATTERY
CPU I/O
218IF-01
ERR
COL
RX
RUN
STRX
TX
INIT
TEST
ONOFF
PORT
10Base-T
MW00400
Ethernet
MW00401
MW00499
MW00400
MW00401
MW00499
MW00498 MW00498
MP3000
(local station)
IP address: 192.168.001.001 IP address: 192.168.001.002
Master
Slave
Communications Protocol
Connect Type
Data Code
Port number: 10003
Port number: 10003
Local Station
Hold registers (M registers)
Read.
Remote Station
Hold registers (M registers)
Data size:
100 words
Data size:
100 words
Extended MEMOBUS protocol
MP2300
(remote station)
Binary
