YASKAWA MP3300 series User Manual

4.2 CPU Module Specifications
4.2.7 System Register Specifications
4-48
• System Work Numbers 17 to 24
System Work
Number
Work 17 Work 18 Work 19 Work 20 Work 21 Work 22 Work 23 Work 24
Executing Main
Program No.
SW03216 SW03217 SW03218 SW03219 SW03220 SW03221 SW03222 SW03223
Status SW04192 SW04250 SW04308 SW04366 SW04424 SW04482 SW04540 SW04598
Control Signals SW04193 SW04251 SW04309 SW04367 SW04425 SW04483 SW04541 SW04599
Fork 0
Program Number SW04194 SW04252 SW04310 SW04368 SW04426 SW04484 SW04542 SW04600
Block Number SW04195 SW04253 SW04311 SW04369 SW04427 SW04485 SW04543 SW04601
Alarm Code
SL26256
(SW04196)
SL26272
(SW04254)
SL26288
(SW04312)
SL26304
(SW04370)
SL26320
(SW04428)
SL26336
(SW04486)
SL26352
(SW04544)
SL26368
(SW04602)
Fork 1
Program Number SW04197 SW04255 SW04313 SW04371 SW04429 SW04487 SW04545 SW04603
Block Number SW04198 SW04256 SW04314 SW04372 SW04430 SW04488 SW04546 SW04604
Alarm Code
SL26258
(SW04199)
SL26274
(SW04257)
SL26290
(SW04315)
SL26306
(SW04373)
SL26322
(SW04431)
SL26338
(SW04489)
SL26354
(SW04547)
SL26370
(SW04605)
Fork 2
Program Number SW04200 SW04258 SW04316 SW04374 SW04432 SW04490 SW04548 SW04606
Block Number SW04201 SW04259 SW04317 SW04375 SW04433 SW04491 SW04549 SW04607
Alarm Code
SL26260
(SW04202)
SL26276
(SW04260)
SL26292
(SW04318)
SL26308
(SW04376)
SL26324
(SW04434)
SL26340
(SW04492)
SL26356
(SW04550)
SL26372
(SW04608)
Fork 3
Program Number SW04203 SW04261 SW04319 SW04377 SW04435 SW04493 SW04551 SW04609
Block Number SW04204 SW04262 SW04320 SW04378 SW04436 SW04494 SW04552 SW04610
Alarm Code
SL26262
(SW04205)
SL26278
(SW04263)
SL26294
(SW04321)
SL26310
(SW04379)
SL26326
(SW04437)
SL26342
(SW04495)
SL26358
(SW04553)
SL26374
(SW04611)
Fork 4
Program Number SW04206 SW04264 SW04322 SW04380 SW04438 SW04496 SW04554 SW04612
Block Number SW04207 SW04265 SW04323 SW04381 SW04439 SW04497 SW04555 SW04613
Alarm Code
SL26264
(SW04208)
SL26280
(SW04266)
SL26296
(SW04324)
SL26312
(SW04382)
SL26328
(SW04440)
SL26344
(SW04498)
SL26360
(SW04556)
SL26376
(SW04614)
Fork 5
Program Number SW04209 SW04267 SW04325 SW04383 SW04441 SW04499 SW04557 SW04615
Block Number SW04210 SW04268 SW04326 SW04384 SW04442 SW04500 SW04558 SW04616
Alarm Code
SL26266
(SW04211)
SL26282
(SW04269)
SL26298
(SW04327)
SL26314
(SW04385)
SL26330
(SW04443)
SL26346
(SW04501)
SL26362
(SW04559)
SL26378
(SW04617)
Fork 6
Program Number SW04212 SW04270 SW04328 SW04386 SW04444 SW04502 SW04560 SW04618
Block Number SW04213 SW04271 SW04329 SW04387 SW04445 SW04503 SW04561 SW04619
Alarm Code
SL26268
(SW04214)
SL26284
(SW04272)
SL26300
(SW04330)
SL26316
(SW04388)
SL26332
(SW04446)
SL26348
(SW04504)
SL26364
(SW04562)
SL26380
(SW04620)
Fork 7
Program Number SW04215 SW04273 SW04331 SW04389 SW04447 SW04505 SW04563 SW04621
Block Number SW04216 SW04274 SW04332 SW04390 SW04448 SW04506 SW04564 SW04622
Alarm Code
SL26270
(SW04217)
SL26286
(SW04275)
SL26302
(SW04333)
SL26318
(SW04391)
SL26334
(SW04449)
SL26350
(SW04507)
SL26366
(SW04565)
SL26382
(SW04623)
Logical Axis 1 Pro-
gram Current Position
SL04218 SL04276 SL04334 SL04392 SL04450 SL04508 SL04566 SL04624
Logical Axis 2 Pro-
gram Current Position
SL04220 SL04278 SL04336 SL04394 SL04452 SL04510 SL04568 SL04626
Logical Axis 3 Pro-
gram Current Position
SL04222 SL04280 SL04338 SL04396 SL04454 SL04512 SL04570 SL04628
Logical Axis 4 Pro-
gram Current Position
SL04224 SL04282 SL04340 SL04398 SL04456 SL04514 SL04572 SL04630
Logical Axis 5 Pro-
gram Current Position
SL04226 SL04284 SL04342 SL04400 SL04458 SL04516 SL04574 SL04632
Logical Axis 6 Pro-
gram Current Position
SL04228 SL04286 SL04344 SL04402 SL04460 SL04518 SL04576 SL04634
Logical Axis 7 Pro-
gram Current Position
SL04230 SL04288 SL04346 SL04404 SL04462 SL04520 SL04578 SL04636
Logical Axis 8 Pro-
gram Current Position
SL04232 SL04290 SL04348 SL04406 SL04464 SL04522 SL04580 SL04638
Continued on next page.
