1.3 Devices and Components That Are Required to Build a System
1.3.1 MP3300 Module/Unit List
1-7
1.3.1
MP3300 Module/Unit List
The following table lists the MP3300 Modules and Units.
* Refer to the following section for details.
3.2.3 Motion Control Function Modules (SVC, SVC32, SVR, and SVR32) on page 3-47
I/O Modules with MECHATROLINK-III
Communications
64-point I/O
Module
Used to input or output digi-
tal, analog, or pulse train
signals.
JEPMC-
MTD2310-E
24 VDC, 64 inputs, 64 outputs
Analog Input
Module
JEPMC-
MTA2900-E
8 analog input channels
Analog Out-
put Module
JEPMC-
MTA2910-E
4 analog output channels
Pulse Train
Input Module
JEPMC-
MTP2900-E
2 pulse-train inputs
Pulse Train
Output Mod-
ule
JEPMC-
MTP2910-E
4 pulse-train outputs
MPE720 Integrated
Engineering Tool Version
7
Used to adjust, maintain,
and program AC Servo
Drives and Inverters that are
connected to the network.
CPMC-
MPE780D
−
Expansion Interface
Module Cables
Used to use an Expansion
Interface Module to connect
the Main Rack to an Expan-
sion Rack or to connect two
Expansion Racks.
JEPMC-
W2094-A5-E
Length: 0.5 m
JEPMC-
W2094-01-E
Length: 1.0 m
JEPMC-
W2094-2A5-E
Length: 2.5 m
− Panel-mounting Bracket
Used to mount the MP3300
inside a control panel.
JEPMC-
OP2300S-E
−
Continued from previous page.
No. Name Use Model Remarks
Type Abbreviation Model Description
CPU Module for 16 axes
CPU-301 (16 axes) JAPMC-CP3301-1-E −
CPU-302 (16 axes) JAPMC-CP3302-1-E −
Motion Control
Function Modules
SVC − MECHATROLINK-III
SVR − Virtual axes*
Communications
Function Module
218IFD − Ethernet
CPU Module for for 32 axes
CPU-301 (32 axes) JAPMC-CP3301-2-E −
CPU-302 (32 axes) JAPMC-CP3302-2-E −
Motion Control
Function Module
SVC32 − MECHATROLINK-III
SVR32 − Virtual axes*
Communications
Function Module
218IFD − Ethernet
Base Unit
MBU-303 JEPMC-BU3303-E 3 slots
MBU-304 JEPMC-BU3304-E 1 slot
To Next Page
