YASKAWA MP3300 series User Manual

1.3 Devices and Components That Are Required to Build a System
1.3.2 Optional Modules
1-8
1.3.2 Optional Modules
You can add the Optional Modules that are listed in the following table for as many open slots
there are in the Base Unit.
* Refer to the manuals for individual Optional Modules for details.
Unit Abbreviation Model Description
Motion
Modules
SVC-01 JAPMC-MC2320-E MECHATROLINK-III × 1
SVB-01 JAPMC-MC2310-E MECHATROLINK-II × 1
SVA-01 JAPMC-MC2300 2-axis analog servo interface
PO-01 JAPMC-PL2310-E 4-axis control with pulse-train output
MPU-01 JAPMC-CP2700-E
Optional Module with CPU Module and SVC-01
functionality
MECHATROLINK-III × 1
Communica-
tions Modules
217IF-01 JAPMC-CM2310-E RS-232C/RS-422 communications
218IF-01 JAPMC-CM2300-E RS-232C/Ethernet communications (10Base-T)
218IF-02 JAPMC-CM2302-E
RS-232C/Ethernet communications (100Base-TX/
10Base-T)
260IF-01 JAPMC-CM2320-E RS-232C/DeviceNet communications
261IF-01 JAPMC-CM2330-E RS-232C/PROFIBUS communications
262IF-01 JAPMC-CM2303-E FL-net communications
263IF-01 JAPMC-CM2304-E EtherNet/IP communications
264IF-01 JAPMC-CM2305-E EtherCAT (EtherCAT slave)
265IF-01 JAPMC-CM2390-E
CompoNet (I/O communications and message
communications)
266IF-01 JAPMC-CM2306-E PROFINET master
266IF-02 JAPMC-CM2307-E PROFINET slave
267IF-01 JAPMC-CM23A0 CC-Link master
215AIF-01
JAPMC-CM2360-E RS-232C/MPLINK communications
JAPMC-CM2361 RS-232C/CP-215 communications
AFMP-01 − Anywire-Master DB by Anywire Corporation
AFMP-02-C − CC-Link by Anywire Corporation
AFMP-02-CA −
CC-Link and Anywire-Master DB by Anywire Cor-
poration
MPANL00-0 − A-net/A-Link by ALGO System
MPALL00-0 − A-Link/A-Link by ALGO System
MPAL000-0 − A-Link by ALGO System
MPAN000-0 − A-net by ALGO System
MPCUNET-0 − CUnet by ALGO System
I/O
Modules
LIO-01 JAPMC-IO2300-E 16 inputs, 16 sinking outputs, 1 pulse-train input
LIO-02 JAPMC-IO2301-E 16 inputs, 16 sourcing outputs, 1 pulse-train input
LIO-04 JAPMC-IO2303-E 32 inputs, 32 sinking outputs
LIO-05 JAPMC-IO2304-E 32 inputs, 32 sourcing outputs
LIO-06 JAPMC-IO2305-E
8 digital inputs, 8 digital sinking outputs
1 analog input channel and 1 analog output chan-
nel
1 pulse-train counter channel
DO-01 JAPMC-DO2300-E 64 sinking outputs
AI-01 JAPMC-AN2300-E 8 analog input channels
AO-01 JAPMC-AN2310-E 4 analog output channels
CNTR-01 JAPMC-PL2300-E 2 counter channels, input circuits: 5 V or 12 V
Expansion
Interface
Module
EXIOIF JAPMC-EX2200-E −
