5.2 Base Units
5-3
5.2
Base Units
One-slot Base Unit
Mounted to DIN ra il: (7)
Unit : mm
Approx. weight: 0.4 kg
Mounted to DIN rail: (15)
64
130
(21) 108
7
50.3 35.5
