4.2 CPU Module Specifications
4.2.7 System Register Specifications
4-56
Alarm Details
Alarm details are given based on the alarm details format.
• Alarm Detail Format = 1 (operation error)
• Alarm Detail Format = 2 (I/O error)
• Alarm Detail Format = 3 (other error)
Product information
The data in these registers give information on the CPU Module.
Register Address Remarks Register Address Example
SW + 9 Error Drawing No. SW16212
SW + 10 Calling Drawing No. SW16213
SW + 11 Calling Drawing Step No. SW16214
SW + 12 Reserved for system. SW16215
SW + 13 Reserved for system. SW16216
Register Address Remarks Register Address Example
SW + 9 Depends on the specifications of the Optional Module. SW16212
SW + 10 Depends on the specifications of the Optional Module. SW16213
SW + 11 Depends on the specifications of the Optional Module. SW16214
SW + 12 Depends on the specifications of the Optional Module. SW16215
SW + 13 Depends on the specifications of the Optional Module. SW16216
Register Address Remarks Register Address Example
SW + 9 Reserved for system. SW16212
SW + 10 Reserved for system. SW16213
SW + 11 Reserved for system. SW16214
SW + 12 Reserved for system. SW16215
SW + 13 Reserved for system. SW16216
Name Register Address Remarks
Serial ID Information
SW20000
CPU Module serial ID
(15 ASCII characters + NULL character)
SW20001
SW20002
SW20003
SW20004
SW20005
SW20006
SW20007
SW20008 to SW20015 Reserved for system.
Reserved for system. SW20016 to SW22063 −
To Next Page
