2.1 CPU Module
2.1.2 Display and Indicators
2-6
Ethernet Status Indicators
These indicators show the status of Ethernet communications.
Indicator Name Color Status When Not Lit, Lit, or Flashing
LINK/ACT Yellow
Lit: Ethernet link established.
Flashing: Ethernet communications activity.
100M Green
Not lit: 10 M connection
Lit: 100 M connection
To Next Page
