YASKAWA V1000 MMD

2 Mechanical Installation
EN 14 YASKAWA Europe TOEP C710606 101A - V1000 MMD IP65 Motor Mounted Drive - Quick Start Guide
3. Remove the motor cables (D) from the terminal block (E) and remove terminal block
(E) from the motor.
4. Fix the earth cable delivered with the collar at the motor ground terminal.
D
E
