YASKAWA V1000 MMD

2 Mechanical Installation
EN 18 YASKAWA Europe TOEP C710606 101A - V1000 MMD IP65 Motor Mounted Drive - Quick Start Guide
13.Re-attach the 2 cables (J) to lid (H).
14.Re-attach the lid (H) to the drive (G) and torque the five screws that fix the lid to
1.3 Nm.
The Drive Package is ready for use.
G
H
J
H
5xM4
1.3 Nm
G
