| Introduction | 21
Button Name Description
③
Mute Key During a call, tap the mute button to mute or unmute.
④
Hang up Key End or reject a call.
⑤
Answer Key Answer a call.
VCR20 Remote Control
The VCR20 remote control enables you to operate the system, including receiving meeting calls,
controlling the camera, adjusting the volume and so on. The following table introduces the keys on the
remote control.
Name Description
①
Tracking Mode Key
• For UVC40:
Press and hold the Tracking Mode key to switch among the
Auto framing, Speaker tracking, or Off.
• For UVC84/UVC80/UVC50:
Press and hold the Tracking Mode key to switch among the
Auto framing or Off.
• For UVC86
Press and hold the Tracking Mode key to switch among the
Auto framing, Speaker tracking, Presenter mode or Off.
②
Mute Key Mute or unmute the microphone.
③
Navigation Key Pan and tilt the camera to adjust the viewing angle.
④
Scroll Wheel
• Scroll up to zoom camera in
• Scroll down to zoom camera out
To Next Page
