| Introduction | 23
Port Name Description
1 USB Cable Connect to the laptop.
2 VC Hub Port Connect to the UVC86/UVC84/UVC80/UVC50.
Note: The BYOD-Extender supports MVC400, MVC640-Wireless, and MVC840.
Technical Specifications
Operating System Windows 10 IoT Enterprise (64-bit)
Software Microsoft Teams Rooms
Processor/SSD/RAM
• Mini-PC: 7th Gen Intel
®
Core
™
i5/128GB/8GB (2 x 4GB)
• MCore: 8th Gen Intel
®
Core
™
i5/128GB/8GB (2 x 4GB)
Mini-PC ports
• 2 x HDMI video output
• Bluetooth and Wi-Fi
• 4 x USB3.0 Type-A
• 1 x 10/100/1000M Ethernet port
• 1 x Power port
