Yealink SIP-T27G Administrator's Guide

Administrator’s Guide for SIP-T2 Series/T4 Series/T5 Series/CP920 IP Phones
272
Macro Action Description
Example: 4411$Cwc$$Cp10$ defines dialing 4411 > > waitconnect > > con-
nected and lasts 10 seconds.
$T<type>$
The embedded action type. Multiple actions can be defined. Supported action
types include:
l invite
l dtmf
l refer
l intercom
Example: *338$Tdtmf$ defines sending the *338 by the type of DTMF.
Note: We recommend that you always define this field. If not, the supplied
digits are dialed using INVITE.
$M<macro>$
The embedded macro. The <macro > string must begin with a letter. If the
macro name is not defined, the execution of the action string will be ignored.
Example: $MAA$ means invoking the EDK macro AA.
$S<softkey ID>$
It has the same effect as pressing the desired soft key.
Each soft key has a unique identifier on the IP phone, you can configure this
parameter according to the system-defined softkey ID. If the softkey ID is not
defined on the phone or there is no matched soft key on the current screen,
the execution of the action string will be ignored. The softkey ID is case-insens-
itive.
Example: $Sanswer$ means pressing the Answer soft key.
Yealink phones support customizing soft keys. When the phone invokes a cus-
tom soft key, the prefix “#” must be added.
Example: If the custom softkey label is IVR1, the custom softkey ID is custom_
macro, then $S#custom_macro$ means pressing the IVR1 soft key.
Note: To view the softkey ID, you can set “features.enhanced_dss_key-
s.enable” and “edk.id_mode.enable” to 1 (Enabled) and then long press the
Volume Up key when the phone is idle.
$K<key name>$
The functionality of performing this action is the same as that of pressing the
desired hard key.
Supported key names include:
l LineKeyX (for T57W/T48U/T48S/T48G, X=29; for
T54W/T46U/T46S/T46G/T29G, X=27; for T42U/T42G/T42S/T41P/T41S,
X=15; for T53W/T53/T43U/T27G, X=21; for T40P/T40G/T23P/T23G, X=3;
for T21(P) E2, X=2).
l SoftKeyX (X ranges from 1 to 4)
l ArrowUp (not applicable to T57W)
l ArrowDown (not applicable to T57W)
l ArrowLeft (not applicable to T57W)
l ArrowRight (not applicable to T57W)
l VolDown
l VolUp
l Cancel (not applicable to T57W)
l OK (not applicable to T57W)
l DialPadX (X ranges from 0 to 9)

Yealink SIP-T27G Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black, Gold
Wall mountable	Yes
Display diagonal	3.66 \
Display resolution	240 x 120 pixels
RJ-9 ports quantity	2
USB 2.0 ports quantity	1
Voice codecs	CNG, G.711, G.722, G.723.1, G.726, G.729, G.729ab, VAD, iLBC
Dual-Tone Multi-Frequency (DTMF) modes	SIP info
Lines quantity	8 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Bluetooth	-
Security algorithms	AES, MD5
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN interface type	Gigabit Ethernet
Volume control	Digital
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	210 mm
Width	265 mm
Height	170.5 mm
