Yealink SIP-T46G User Manual

Customizing Your Phone
91
When you assign functionality to line key located in line key 11-27, the label of the line key
10-18 are indicated on the second page, and the labels of the line key 19-27 are indicated on
the third page. The line key in the right bottom is used to switch pages. The following figure
shows an example:
The following table lists the page icons:
Icons
Description
Indicates the current page of line keys.
Indicates the non-current page of line keys.
Page Tips
You can use page tips feature to enable the page icon and page switch key LED to indicate
different statuses. This feature is disabled by default.
The following table lists the page icons to indicate different statuses:
Icons
Description
Fast flashing: the BLF monitored user receives an incoming call on
the non-current page.
Solid: there is a parked call on the non-current page.
Fast flashing: the line receives an incoming call on the
non-current page.
For more information on the page switch key LED status, refer to LED Instructions on page 9.
2
3
1
1
1

Yealink SIP-T46G Specifications

General

Backlight	Yes
Power requirements	100-240V, DC 5V
Touchscreen	-
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723, G.726, G.729A, G.729B
Bluetooth	No
RJ-9 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	185 mm
Width	244 mm
Height	213 mm
