Yealink SIP-T46S Administrator's Guide

Phone Customization
263
Pro-
grammable
Key IDs
CP920
T19(P)
E2
T23P/T23G/T2-
1(P) E2
T29G/T27-
G
T53W/T53/T43U/
T42G/T42S/T42-
U/
T41P/T41S
/T40P/T40G
T54W/T48U/T48G/
T48S/T46U/T46S/T46-
G
T57W
1
SoftKey-
1
SoftKey1 SoftKey1 SoftKey1 SoftKey1 SoftKey1 SoftKey1
2
SoftKey-
2
SoftKey2 SoftKey2 SoftKey2 SoftKey2 SoftKey2 SoftKey2
3
SoftKey-
3
SoftKey3 SoftKey3 SoftKey3 SoftKey3 SoftKey3 SoftKey3
4
SoftKey-
4
SoftKey4 SoftKey4 SoftKey4 SoftKey4 SoftKey4 SoftKey4
5 Up Up Up Up Up Up /
6 Down Down Down Down Down Down /
7 / Left Left Left Left Left /
8 / Right Right Right Right Right /
9 OK OK OK OK OK OK /
10 / / Cancel Cancel Cancel Cancel /
11 / / / CONF / / /
12 / / / HOLD / HOLD HOLD
13 MUTE MUTE / MUTE MUTE MUTE MUTE
14 / TRAN TRAN TRAN / TRAN TRAN
17 / Redial Redial Redial Redial Redial Redial
18 /
Mes-
sage
Message Message Message Message
Mes-
sage
Programmable Keys Configuration
For T23P/T23G/T21(P) E2 phones, Cancel key can be configured only when “features.keep_mute.enable” is set to
0 (Disabled).
For other phones, Mute key can be configured only when “features.keep_mute.enable” is set to 0 (Disabled).
The following table lists the parameters you can use to configure programmable keys.
Parameter
programablekey.type_range.custom <y0000000000xx>.cfg
Description
It configures the list for available programmable key types when configuring programmable keys.
To assign function types, specify programmable key type IDs which start with or without a symbol ”+”.
For example, “+2,15,16,7,4” or “2,15,16,7,4” means only “N/A”, “Forward”, “Line”, “BLF”, “Recall”,
“Hold” types are available when you configure programmable keys.
To remove a function type, specify programmable key type IDs which start with the symbol “-”. For
example, “-14, 5, 2” means to remove “Intercom”, “DND”, “Forward” types from the Dsskey function
types list. These programmable key types are not available when you configure programmable keys.
Note: Multiple programmable key type IDs are separated by commas. “N/A” type is always kept.

Yealink SIP-T46S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	10
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
Package depth	255 mm
Package width	274 mm
Package height	128 mm
