Administrator’s Guide for SIP-T2 Series/T4 Series/T5 Series/CP920 IP Phones
477
Contact: <sip:3586@10.2.40.27:5063 >
Max-Forwards: 70
User-Agent: Yealink SIP-T46G
Event: ACTION-URI
Content-Type: message/sipfrag
Content-Length: 6
Message Body
key=OK
Variable Values List
Yealink phones also support a combination of the variable values in the URI, but the order of the variable value is
determined by the operation of the phone. The valid URI format is: http(s)://<phoneIPAddress>/servlet?key=variable
value[;variable value]. Variable values are separated by a semicolon from each other. This method is not applicable
to T57W/T48U/T48S/T48G phones.
The following shows an example for deleting all entries from the call history list when the phone is idle:
For CP920 phones:
http://10.3.20.10/servlet?key=F1;OK;F3;DOWN;DOWN;DOWN;OK;OK.
For other phones:
http://10.3.20.10/servlet?key=F1;F3;DOWN;DOWN;DOWN;OK;OK.
Note: The variable value is not applicable to all events. For example, the variable value “MUTE” is only applicable when the
IP phone is during a call.
When authentication is required, you can use the following URI format: http(s)://user-
name:password@<phoneIPAddress>/servlet?key=variable value. If you are using a browser, we recommend that
you use Firefox.
The following table lists predefined variable values:
Variable Value Phone Action
OK Press the OK/√key. (not applicable to T57W phones)
ENTER
Press the Enter soft key. (not applicable to T57W/T48U/T48S/T48G
phones)
SPEAKER Press the Speakerphone key. (not applicable to CP920 phones)
F_TRANSFER Transfer a call to another party.
VOLUME_UP Increase the volume.
VOLUME_DOWN Decrease volume.
MUTE Mute a call.
F_HOLD/HOLD Place an active call on hold.
F_CONFERENCE
Press the Conf/Conference soft key.

Yealink SIP-T46S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	10
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
Package depth	255 mm
Package width	274 mm
Package height	128 mm
