Yealink SIP-T46S Administrator's Guide

General Features
496
Parameter
sip.timer_t1 <y0000000000xx>.cfg
Description
It configures the SIP session timer T1 (in seconds).
Permitted
Values
Float from 0.5 to 10
Default
0.5
Web UI
Settings > SIP > SIP Session Timer T1 (0.5~10s)
Parameter
sip.timer_t2 <y0000000000xx>.cfg
Description
It configures the SIP session timer T2 (in seconds).
Permitted
Values
Float from 2 to 40
Default
4
Web UI
Settings > SIP > SIP Session Timer T2 (2~40s)
Parameter
sip.timer_t4 <y0000000000xx>.cfg
Description
It configures the SIP session timer T4 (in seconds).
Permitted
Values
Float from 2.5 to 60
Default
5
Web UI
Settings > SIP > SIP Session Timer T4 (2.5~60s)
Session Timer
Session timer allows a periodic refresh of SIP sessions through an UPDATE request, to determine whether a SIP
session is still active. Session timer is specified in RFC 4028. The phones support two refresher modes: UAC and
UAS. Whether the endpoint functions as a UAC or a UAS depends on the UA that initiates the SIP request. If the ini-
tiator is configured as UAC, the other client or the SIP server will function as a UAS. If the initiator is configured as
UAS, the other client or the SIP server will function as a UAC. The session expiration is negotiated via the Session-
Expires header in the INVITE message. The negotiated refresher is always the UAC and it will send an UPDATE
request at the negotiated session expiration. The value “refresher=uac” included in the UPDATE message means
that the UAC performs the refresh.
Example of UPDATE message (UAC mode):
UPDATE sip:1058@10.10.20.34:5060 SIP/2.0
Via: SIP/2.0/UDP 10.10.20.32:5060;branch=z9hG4bK2104991394
From: "10111" <sip:10111@10.2.1.48:5060 > ;tag=2170397024
To: <sip:1058@10.2.1.48:5060 > ;tag=200382096
Call-ID: 4_1556494084@10.10.20.32
CSeq: 2 UPDATE
Contact: <sip:10111@10.10.20.32:5060 >
Max-Forwards: 70
User-Agent: Yealink SIP-T46G 28.82.0.20
Session-Expires: 90;refresher=uac

Yealink SIP-T46S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	10
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
Package depth	255 mm
Package width	274 mm
Package height	128 mm
