Yealink SIP-T46S Administrator's Guide

Phone Provisioning
72
Attributes
Description
Note: Exclude mode can only be used in boot files. If a boot file is used but “stat-
ic.specific_model.excluded_mode” is not configured, the exclude mode is dis-
abled by default.
Tip: The line beginning with “#” is considered to be a comment. You can use “#” to make any comment on the boot file.
Customizing a Boot File
Procedure
1.
Open a boot template file.
2.
To add a configuration file, add include:config < > or include:config “” to the file. Each starts on a separate line.
3.
Specify a configuration file for downloading.
For example:
include:config <configure/sip.cfg >
include:config “http://10.2.5.206/configure/account.cfg”
include:config “http://10.2.5.206/configure/dialplan.cfg”
4.
To specify configuration files for specific phone models, add specific phone models in front of include:config < >
or include:config “”. Multiple phone model names are separated by commas.
For example:
[T46S, T48S]include:config <configure/sip.cfg >
[T23G]include:config “http://10.2.5.206/configure/account.cfg”
## file sip.cfg only applies to T46S and T48S phones, file account.cfg only applies to T23G phones
5.
Specify the overwrite mode and exclude mode.
For example:
overwrite_mode = 1
static.specific_model.excluded_mode = 1
6.
Save the boot file and place it on the provisioning server.
Related Topic
Boot File Attributes
Configuration Files
Yealink supports two configuration template files: Common CFG file and MAC-Oriented CFG file.
These configuration files contain two kinds of parameters:
l Static: The parameters start with a prefix “static.”, for example, static.auto_provision.custom.protect.
l Non-static: The parameters do not start with a prefix “static.”, for example, local_time.date_format.
You can deploy and maintain a mass of Yealink phones automatically through configuration files stored in a pro-
visioning server.
Note: For protecting against unauthorized access, you can encrypt configuration files. For more information on encrypting
configuration files, refer to Encrypting and Decrypting Files.
Topics
Common CFG File
MAC-Oriented CFG File
MAC-local CFG File
Configuration File Customization
Configuration File Attributes

Yealink SIP-T46S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	10
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
Package depth	255 mm
Package width	274 mm
Package height	128 mm
