Yealink SIP-T46S Administrator's Guide

Administrator’s Guide for SIP-T2 Series/T4 Series/T5 Series/CP920 IP Phones
272
Macro Action Description
Example: 4411$Cwc$$Cp10$ defines dialing 4411 > > waitconnect > > con-
nected and lasts 10 seconds.
$T<type>$
The embedded action type. Multiple actions can be defined. Supported action
types include:
l invite
l dtmf
l refer
l intercom
Example: *338$Tdtmf$ defines sending the *338 by the type of DTMF.
Note: We recommend that you always define this field. If not, the supplied
digits are dialed using INVITE.
$M<macro>$
The embedded macro. The <macro > string must begin with a letter. If the
macro name is not defined, the execution of the action string will be ignored.
Example: $MAA$ means invoking the EDK macro AA.
$S<softkey ID>$
It has the same effect as pressing the desired soft key.
Each soft key has a unique identifier on the IP phone, you can configure this
parameter according to the system-defined softkey ID. If the softkey ID is not
defined on the phone or there is no matched soft key on the current screen,
the execution of the action string will be ignored. The softkey ID is case-insens-
itive.
Example: $Sanswer$ means pressing the Answer soft key.
Yealink phones support customizing soft keys. When the phone invokes a cus-
tom soft key, the prefix “#” must be added.
Example: If the custom softkey label is IVR1, the custom softkey ID is custom_
macro, then $S#custom_macro$ means pressing the IVR1 soft key.
Note: To view the softkey ID, you can set “features.enhanced_dss_key-
s.enable” and “edk.id_mode.enable” to 1 (Enabled) and then long press the
Volume Up key when the phone is idle.
$K<key name>$
The functionality of performing this action is the same as that of pressing the
desired hard key.
Supported key names include:
l LineKeyX (for T57W/T48U/T48S/T48G, X=29; for
T54W/T46U/T46S/T46G/T29G, X=27; for T42U/T42G/T42S/T41P/T41S,
X=15; for T53W/T53/T43U/T27G, X=21; for T40P/T40G/T23P/T23G, X=3;
for T21(P) E2, X=2).
l SoftKeyX (X ranges from 1 to 4)
l ArrowUp (not applicable to T57W)
l ArrowDown (not applicable to T57W)
l ArrowLeft (not applicable to T57W)
l ArrowRight (not applicable to T57W)
l VolDown
l VolUp
l Cancel (not applicable to T57W)
l OK (not applicable to T57W)
l DialPadX (X ranges from 0 to 9)

Yealink SIP-T46S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	10
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
Package depth	255 mm
Package width	274 mm
Package height	128 mm
