Yealink SIP-T46S Administrator's Guide

Administrator’s Guide for SIP-T2 Series/T4 Series/T5 Series/CP920 IP Phones
465
Variable Value Description
$mac The MAC address of the IP phone.
$ip The IP address of the IP phone.
$model The IP phone model.
$firmware The firmware version of the IP phone.
$active_url
The SIP URI of the current account when the IP phone places a call, receives an incoming
call or establishes a call.
$active_user
The user part of the SIP URI for the current account when the IP phone places a call,
receives an incoming call or establishes a call.
$active_host
The host part of the SIP URI for the current account when the IP phone places a call,
receives an incoming call or establishes a call.
$local
The SIP URI of the caller when the IP phone places a call.
The SIP URI of the callee when the IP phone receives an incoming call.
$remote
The SIP URI of the callee when the IP phone places a call.
The SIP URI of the caller when the IP phone receives an incoming call.
$display_local
The display name of the caller when the IP phone places a call.
The display name of the callee when the IP phone receives an incoming call.
$display_remote
The display name of the callee when the IP phone places a call.
The display name of the caller when the IP phone receives an incoming call.
$call_id The call-id of the active call.
$callerID The display name of the caller when the IP phone receives an incoming call.
$calledNumber The phone number of the callee when the IP phone places a call.
$exp_number The number of connected expansion modules.
$ehs_number The number of connected EHS.
$udisk_number The number of connected USB flash drives.
$usbheadset_number The number of connected USB headset devices.
$wifi_number The number of connected Wi-Fi dongles.
$bluetooth_number The number of connected Bluetooth dongles.
$vpn_ip The phone IP address assigned by the VPN server.
$cfg_all
The CFG configuration file contains all current configurations of the IP phone.
Note: The valid URI is: http://<serverIPAddress>/<filename>/?variable name=$variable
value.
Example:
http://10.82.21.10/Upload/?Cfg=$cfg_all
$cfg_local
The CFG configuration file contains all non-static parameters made via the phone user
interface and web user interface.
Note: It works only if “static.auto_provision.custom.protect” is set to 1 (Enabled). The valid
URI is: http://<serverIPAddress>/<filename>/?variable name=$variable value.
Example:

Yealink SIP-T46S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	10
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
Package depth	255 mm
Package width	274 mm
Package height	128 mm
